A 1 Day Course on

LNG Storage Tanks: Design, Construction & Operation (LNGSTO)

17 October 2024
Dubai, UAE

Register

Overview

In the realm of LNG logistics, while numerous courses focus on its transportation via ships, fewer focus on crucial aspects of LNG storage tanks at import/export terminals. This one-day course offers a comprehensive insight into the basic design, construction, and operation of LNG storage tanks, expounding on the fundamentals of cryogenic storage and the safety features inherent in above-ground LNG tanks.

Aligned with industry standards such as API 625, API 650, and API 620, which govern large, welded, low-pressure storage tanks including LNG tanks, this course delves into the intricacies of tank design and construction without endorsing specific manufacturers or equipment. Instead, it aims to familiarize participants with the diverse array of tanks available internationally.

Participants will gain a thorough understanding of:

  • The basic design and construction of LNG storage tanks, including materials and equipment specifications
  • The process of transferring liquid gas to LNG tanks from ships and subsequent re-gasification

PRIMARY AREAS OF FOCUS

  • Understand LNG tank design basics including structural integrity
  • Explore industry standards of API 625, API 650 & API 620, for large, welded, low-pressure storage tanks/LNG Tanks
  • Learn seismic safety measures and containment strategies
  • Explore quick construction methods of slip forming and air-raising
  • Study 9% Ni steel and concrete for durability
  • Optimize boil off, re-gasification and insulation
  • Focus on testing and instrumentation for quality control & risk mitigation
  • Apply knowledge to LNG operations, project management, and engineering

Who Should Attend

This course is particularly beneficial for individuals involved in LNG import or export terminals and is also relevant for those new to the LNG industry including storage tank design engineers, construction managers, environmental & health safety specialists, regulatory compliance officers, maintenance engineers, cryogenic tank operators, and inspection and quality assurance officers.

Refiners

Terminal Operators, Maintenance/Inspection

Consultants

Tank, Operations, Storage

Professionals

Engineers, Construction, Superintendents

Managers

Tank Farm Operators, Environmental, health & safety, Regulatory compliance, Inspection & quality assurance


Course Direc​​tor

Dr Brian Quinn
Marine Consultant Associates
Edinburgh, Scotland




Mantle Consultant Associates focuses on providing advice and technical assistance primarily within the storage tank industry with our Course Leader Dr Brian Quinn having more than 40 years’ experience and expertise in the international storage tankage business industry. A Chartered Mechanical Engineer from the University of West Scotland, Dr Brian Quinn is a specialist in the use of aluminium alloys in complex Aluminium structures and has provided independent and practical advice on a complicated subject to many companies in the UK, Middle East and Asia, on the design and operation of storage tanks.

Prior to starting Mantle Consultant Associates, Dr Brian Quinn worked at Toyo Kanetsu KK (TKK) as the GM for the Middle East in Abu Dhabi, Resident Engineer of Mobil Oil based in Norway and Site Manager/Project Manager for Motherwell Bridge Engineering based in the UK and UAE.


Attendees Will Learn To:

  • Gain a comprehensive understanding of the design and construction of LNG storage tanks
  • Explore  materials and equipment specifications
  • Learn the process of transferring liquid gas to LNG tanks and re-gasification
  • Gain in-depth knowledge of Full Containment LNG Tanks


Programme at a Glance

​Introduction to LNG


 • Single Containment
• Double Containment
• Full Containment

Single - consists of a single wall or shell enclosing the LNG storage volume. Double - consists of an inner tank (primary container) surrounded by an outer tank (secondary container), providing an additional layer of protection against leaks or spills. Full - features both an inner tank and an outer tank, with the space between them serving as a containment area. This design offers the highest level of safety and environmental protection.

• Base Slab
• Piled
• Insulation


The base slab provides a stable foundation for the LNG tank and distributes the load evenly to the underlying soil or piles. Piles are driven deep into the ground to support the weight of the LNG tank and transfer loads to deeper, more stable soil layers. Insulation may be applied to the tank foundation to minimize heat transfer from the ground and prevent frost heave or settlement

• Internal 9% Ni Steel

• External Prestressed Concrete

• Insulation

The internal shell of the LNG tank is typically made of 9% Ni steel to withstand low temperatures and maintain structural integrity. The external shell of the LNG tank may be constructed using prestressed concrete to provide additional strength and protection against environmental factors. Insulation is applied to the tank shell to minimize heat transfer and maintain the cryogenic temperature of the LNG inside

• Inner Suspended
• Outer Reinforced Concrete
• Insulation

The inner roof is suspended from the top of the tank shell and may be insulated to prevent heat ingress. The outer roof is typically made of reinforced concrete and provides protection against weather and external forces. Insulation is applied to the tank roof to minimize heat transfer and maintain the low temperature required for LNG storage.

• Hydrotest
• Boil Off

Assesses the structural integrity of the LNG tank by pressurizing it with water to a specified level and checking for leaks or deformation. Boil off maintains safe operating conditions and prevents excessive vapor pressure buildup

• Includes sensors, gauges, and control systems installed on the LNG tank to monitor parameters such as temperature, pressure, and liquid level
• Equipment fitted include valves, fittings, and connections used for loading, unloading, and transferring LNG to and from the tank

Attend This Event With a Two-Day Course on


This two-day workshop will provide a basic understanding of storage tanks, how they are operated, managed and maintained, and explain the concept of vapour emissions and how to measure and control them on existing and new-build tanks, in order to ensure a safe and environmentally acceptable storage tank facility.
